IF04 Inframe Battery
Vestel’s most compact in-frame battery, IF04 hides completely inside the frame and delivers 360 Wh of power—perfect for space-sensitive city bikes with a minimalist look.
IF04 Inframe Battery
Vestel’s most compact in-frame battery, IF04 hides completely inside the frame and delivers 360 Wh of power—perfect for space-sensitive city bikes with a minimalist look.
Different mounting options like rear carier downtube or in frame. Different capacities from 360Wh to 540Wht
Easy monitoring via mobile app over BLE
EN50604 certified
Reliable with laser welding technology
TECHNICAL INFORMATION
TECHNICAL INFORMATION
| Nominal Voltage | 36V |
| Capacity | 360 Wh |
| Cells | 21700, 5Ah /5.3Ah |
| Battery Pack | 10S2P |
| Charge Connector | 25A (min 2500 cycles) |
| Discharge Connector | 25A (min 2500 cycles) |
| Weight | 2,4kg |
| Dimensions (mm) | 457*60*52 |
| Communication Protocols | CAN, UART |
| Indicators | RGB LED |
| IP Level | IP66 |
| Mobile App Support | over Bluetooth |
| Other Features | Leaser Welding |
| Certifications | EN50604-1, UN38.3, IEC62133-2 |
| Warranty | 3 years or 1.000 cycles |
